Image sensor
1/2.7” progressive scan RGB CMOS
Lens
IR-corrected i-CS lens
Varifocal 3.9–10 mm, F1.5
4:3 aspect ratio:
Horizontal field of view: 75°–31°
Vertical field of view: 55°–23°
16:9 aspect ratio:
Horizontal field of view: 75°–31°
Vertical field of view: 41°–17°
Remote zoom, remote focus
Day and night
Automatically removable infrared-cut filter
Minimum illumination
5 MP 25/30 fps with advanced WDR imaging technology and low-light technology:
Color: 0.15 lux, at 50 IRE F1.5
B/W: 0.03 lux, at 50 IRE F1.5
Shutter speed
WDR: 1/33500 s to 1/5 s
No WDR: 1/5000 s to 1/5 s
System on Chip model
Manufacturer’s own chipset (7th gen)
Memory
1 GB RAM, 512 MB Flash
Video compression
H.264 (MPEG-4 Part 10/AVC) Baseline, Main and High Profiles
H.265 (MPEG-H Part 2/HEVC)
Motion JPEG
Resolution
2592x1944 (5 MP) to 160x90
2688x1512 (4 MP) to 160x90
1280x720 (HDTV 720p) to 160x90
Frame rate
Capture mode 5 MP: 25/30 fps (50/60 Hz)
Capture mode 4 MP: 25/30 fps (50/60 Hz)
Capture mode HDTV 720p: 180 fps
Video streaming
Multiple, individually configurable streams in H.264, H.265 and Motion JPEG
Controllable frame rate and bandwidth
VBR/ABR/MBR H.264/H.265
Video streaming indicator
Multi-view streaming
Up to 8 individually cropped out view areas
Image settings
Saturation, contrast, brightness, sharpness, advanced WDR imaging technology: Up to 120 dB
depending on scene, white balance, day/night threshold, exposure mode, exposure zones, local contrast, tone mapping, compression, rotation: auto, 0°, 90°, 180°, 270° including corridor format, mirroring of images, dynamic text and image overlay, privacy masks, defogging, electronic image stabilization, barrel distortion correction, scene profiles: forensic, vivid, traffic overview
Pan/Tilt/Zoom
Digital PTZ
Network protocols
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS, HTTP/2, TLS, QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP™, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, SFTP, TCP, UDP, IGMP, RTCP, ICMP,
DHCPv4/v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf)
Application Programming
Interface
Open API for software integration, including VAPIX® and , specifications at ONVIF® Profile G, ONVIF® Profile S, and ONVIF® Profile T, specification at onvif.org
Onscreen controls
Electronic image stabilization
Day/night shift
Defogging
Wide dynamic range
Event conditions
Analytics, shock detection, edge storage events, supervised external input, audio level,
time scheduled, MQTT subscribe
Event actions
Record video: SD card and network share
Upload of images or video clips: FTP, SFTP, HTTP, HTTPS, network share and email
Pre- and post-alarm video or image buffering for recording or upload
Notification: email, HTTP, HTTPS, TCP and SNMP trap
PTZ: PTZ preset, start/stop guard tour
Overlay text, external output activation, play audio clip, WDR mode, day/night mode
MQTT publish
Data streaming
Event data
Built-in installation
aids
Focus assistant, pixel counter, remote back focus, autorotation
Applications
Included
motion guard, fence guard, loitering guard
video motion detection, active tampering alarm, gatekeeper
Supported
live privacy shield, perimeter defender
Support for enabling installation of third-party applications
Edge security
Software: Signed OS, brute force delay protection, digest authentication and OAuth 2.0 RFC6749 OpenID Authorization Code Flow for centralized ADFS account management, password protection, AES-XTS-Plain64 256bit SD card encryption
Hardware: Secure boot
Network security
IEEE 802.1X (EAP-TLS, PEAP-MSCHAPv2), IEEE 802.1AE (MACsec PSK/EAP-TLS), HTTPS/HSTS,
TLS v1.2/v1.3, Network Time Security (NTS), X.509 Certificate PKI, host-based firewall
Casing
IP68-rated, EN 1.4404 (ASTM 316L) stainless steel casing for maximum corrosion protection
Casing manufactured and certified by Samcon Prozessleittechnik GmbH, www.samcon.eu
Power
Camera: Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 3, max 10.7 W, typical 5.4 W
Heater: 24 V DC, max 40 W
24 V DC is required for operating at temperatures below 0 °C (32 °F).
Connectors
5
m (16 ft) pigtail cable for network (Cat 6, RJ45 connector) and power
Storage
Pre-installed
surveillance grade microSDXC card 128 GB
Support
for SD card encryption (AES-XTS-Plain64 256bit)
Recording
to network-attached storage (NAS)
For
SD card and NAS recommendations, refer to the manufacturer's webpage
Operating conditions
-60
°C to 60°C (-76 °F to 140 °F)
Maximum
temperature according to NEMA TS 2 (2.2.7): 74 °C (165 °F)
Humidity
10-100% RH (condensing)
Storage conditions
-40
°C to 65 °C (-40 °F to 149 °F)
Humidity
5-95% RH (non-condensing)
Approvals
EMC
EN
55035, EN 55032 Class A, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2
Environment
IEC/EN
60529 IP68
Network
NIST
SP500–267
Explosion
EN/IEC 60079-0, EN/IEC 60079-1, EN/IEC 60079-31, TR CU 012/2011, GOST R IEC
60079-0, GOST IEC 60079-1, GOST R IEC 60079-31
Certifications
Model
key: T08-VA2.3.K3.BOR2-LL.H-005.N-P
ATEX:
II 2 G Ex db IIC T5 Gb, II 2 D Ex tb IIIC T95°C Db
Certificate:
TÜV 18 ATEX 8218X
IECEx:
Ex db IIC T5 Gb, Ex tb IIIC T95°C Db
Certificate:
IECEx TUR 18.0023X
IA:
Ex db IIC T5 Gb, Ex tb IIIC T95°C Db
Certificate:
MASC MS/18-3256X
EAC
Ex: 1Ex db IIC T5 Gb, Ex tb IIIC T 95°C Db
Series:
T8, Model: T08-VA2.3.
Certificate:
RU C-DE.HA65.B.01652/22
INMETRO:
Ex db IIC T5 Gb, Ex tb IIIC T95°C Db
Certificate:
TÜV 23.0363X
PESO:
Ex db IIC T5 Gb
Certificate:
A/P/HQ/KA/104/5735
UKCA:
II 2 G Ex db IIC T5 Gb, II 2 D Ex tb IIIC T95 °C Db
Certificate:
TÜV 22 UKEX 7137 X
Dimensions
ø
113 mm (4.4 in)
Height:
160.5 mm (6.3 in )
Length:
334 mm (13.1 in )
Weight
7.8
kg (17.2 lb)
Languages
English,
German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese,
Korean, Portuguese, Traditional Chinese, Dutch, Czech, Swedish, Finnish,
Turkish, Thai, Vietnamese, Polish
Warranty
5-year
warranty
Substance control
PVC
free
Free
of hazardous brominated and chlorinated flame retardants (BFR/CFR free)
RoHS
in accordance with EU RoHS Directive 2011/65/EU/ and EN 63000:2018
REACH
in accordance with (EC) No 1907/2006. For SCIP UUID, see echa.europa.eu
Environmental
responsibility
The
manufacturer is a signatory of the UN Global Compact, read more at
unglobalcompact.org
