Image sensor
1/1.8” progressive scan RGB CMOS
Lens
Varifocal, 3.9–10 mm, F1.5
Horizontal field of view: 120°–47°
Vertical field of view: 63°–27°
Autofocus, i-CS lens, IR corrected, remote zoom and focus, P-Iris control
Minimum focus distance: 0.5 m (1.6 ft)
Day and night
Automatically removable infrared-cut filter
Minimum illumination
4 MP 25/30 fps with advanced WDR imaging technology and Advanced low-light
technology
Color: 0.05 lux at 50 IRE, F1.5
B/W: 0.01 lux at 50 IRE, F1.5
4 MP 50/60 fps with Advanced low-light technology
Color: 0.1 lux at 50 IRE, F1.5
B/W: 0.02 lux at 50 IRE, F1.5
4 MP 25/30 fps with advanced WDR imaging technology and Advanced low-light
technology
With
optional F0.9 lens
Color:
0.02 lux at 50 IRE, F0.9
B/W:
0.004 lux at 50 IRE, F0.9
Shutter speed
1/47500
s to 1 s
System on Chip model
Manufacturer’s
own chipset (8th gen)
Memory
2048
MB RAM, 8194 MB Flash
Compute capabilities
Deep
learning processing unit (DLPU)
Video compression
H.264
(MPEG-4 Part 10/AVC) Baseline, Main and High Profiles
H.265
(MPEG-H Part 2/HEVC) Main Profile
Motion
JPEG
Resolution
16:9
2688x1512 Quad HD to 160x90
4:3
2016x1512 to 160x120
Frame rate
No
WDR: Up to 60/50 fps (60/50 Hz) in all resolutions
WDR:
Up to 30/25 fps (60/50 Hz) in all resolutions
Video streaming
Multiple,
individually configurable streams in H.264, H.265 and Motion JPEG
Controllable
frame rate and bandwidth
VBR/ABR/MBR
H.264/H.265
Low latency mode
Video
streaming indicator
Multi-view streaming
Up
to 8 individually cropped out view areas
Image settings
Saturation,
contrast, brightness, advanced WDR imaging technology: Up to 120 dB depending
on scene, white balance, day/night threshold, tone mapping, exposure mode,
exposure zones, defogging, barrel distortion correction, electronic image
stabilization, compression, rotation: 0°, 90°, 180°, 270° including corridor
format, mirroring, dynamic text and image overlay, polygon privacy mask
Scene
profiles: forensic, vivid, traffic overview
Pan/Tilt/Zoom
Digital
PTZ, preset positions
Uploadable
PTZ driver (Pelco D pre-installed)
Audio streaming
Two-way,
full duplex
Noise
reduction
Audio encoding
24bit
LPCM, AAC-LC 8/16/32/48 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz, Opus 8/16/48
kHz
Configurable
bit rate
Audio input/output
External
microphone input or line input, line output, built-in microphone (can be
disabled), ring power, digital audio input, automatic gain control
Network protocols
IPv4,
IPv6 USGv6, HTTP, HTTPS, HTTP/2, TLS, QoS Layer 3 DiffServ, FTP, SFTP,
CIFS/SMB, SMTP, Bonjour, UPnP®, SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, NTS,
RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SSH,
LLDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS)
Application Programming
Interface
Open
API for software integration, including VAPIX®, metadata, and ; specifications
at /developer-community. application includes Native SDK and Computer Vision
SDK.
ONVIF®
Profile G, ONVIF® Profile M, ONVIF® Profile S, and ONVIF® Profile T,
specification at onvif.org
Onscreen controls
Electronic
image stabilization
Day/night
shift
Defogging
Wide
dynamic range
Video
streaming indicator
Event conditions
Application
Audio:
audio detection, audio clip playing
Device
status: above/below/within operating temperature, IP address blocked, IP
address removed, live stream active, network lost, new IP address, ring power
overcurrent protection, system ready
Digital
audio: digital signal contains metadata, digital signal has invalid sample
rate, digital signal missing, digital signal okay
Edge
storage: recording ongoing, storage disruption, storage health issues detected
I/O:
digital input, manual trigger, virtual input
MQTT:
stateless
PTZ:
PTZ malfunctioning, PTZ movement, PTZ preset position reached, PTZ ready
Scheduled
and recurring: schedule
Video:
average bitrate degradation, day-night mode, tampering
Event actions
Overlay
text, external output activation, play audio clip, zoom preset
I/O:
toggle I/O once, toggle I/O while the rule is active
MQTT:
publish
Notification:
HTTP, HTTPS, TCP, and email
Pre-
and post-alarm video or image buffering for recording or upload
PTZ:
PTZ preset, start/stop guard tour
Record
video: SD card and network share
SNMP
traps: send, send while the rule is active
Upload
of images or video clips: FTP, SFTP, HTTP, HTTPS, network share, and email
Built-in installation
aids
Remote
zoom and focus, remote back focus, leveling assistant, pixel counter
Applications
Included
object
analytics, manufacturer Scene Metadata, manufacturer Image Health Analytics,
live privacy shield
video
motion detection
Support
for enabling installation of third-party applications
Object Analytics
Object
classes: humans, vehicles (types: cars, buses, trucks, bikes, other)
Scenarios:
line crossing, object in area, time in area, crossline counting, occupancy in
area
Up
to 10 scenarios
Other
features: triggered objects visualized with trajectories, color-coded bounding
boxes and tables
Polygon
include/exclude areas
Perspective
configuration
ONVIF
Motion Alarm event
Image health analytics
Detection
settings:
Tampering:
blocked image, redirected image
degradation: blurred image, underexposed image
Other
features: sensitivity, validation period
Scene metadata
Object
classes: humans, faces, vehicles (types: cars, buses, trucks, bikes), license
plates
Object attributes: vehicle color, upper/lower clothing color, confidence,
position
EMC
EN
55032 Class A, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2
Australia/New
Zealand: CISPR 24, CISPR 35, RCM AS/NZS CISPR 32 Class A
Canada:
ICES-3(B)/NMB-3(B)
Japan:
VCCI Class A
Korea:
KS C 9832 Class A, KS C 9815, KS C 9835, KS C 9547
USA:
FCC Part 15 Subpart B Class A
Safety
IEC/EN/UL
62368-1
Environment
IEC
60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC
60068-2-78
Network
NIST
SP500-267
Cybersecurity
ETSI
EN 303 645, FIPS 140
Edge security
Software:
Signed OS, brute force delay protection, digest authentication and OAuth 2.0
RFC6749 OpenID Authorization Code Flow for centralized ADFS account management,
password protection, AES-XTS-Plain64 256bit SD card encryption
Hardware:
cryptographic compute module cybersecurity platform
TPM
2.0 (CC EAL4+, FIPS 140-2 Level 2), secure element (CC EAL 6+), system-on-chip
security (TEE), Manufacturer's device ID, secure keystore, signed video, secure
boot, encrypted filesystem (AES-XTS-Plain64 256bit)
Network security
IEEE
802.1X (EAP-TLS, PEAP-MSCHAPv2), IEEE 802.1AE (MACsec PSK/EAP-TLS), IEEE
802.1AR, HTTPS/HSTS, TLS v1.2/v1.3, Network Time Security (NTS), X.509
Certificate PKI, host-based firewall
Casing
Aluminum
casing
Color:
black NCS S 9000-N
Mounting
¼”-20
UNC tripod screw thread
Sustainability
PVC
free, BFR/CFR free, 0% recycled plastics, 4% bio-based plastics
Power
Power
over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 3
Typical
5.1 W, max 8.2 W
10–28
VDC, typical 4.6 W, max 7.7 W
Power
redundancy
Connectors
RJ45
10BASE-T/100BASE-TX/1000BASE-T PoE
Terminal
block for two supervised and two unsupervised configurable inputs / digital
outputs (12 VDC output, max load 50 mA)
RS485/RS422,
2 pcs, 2 pos, full duplex, terminal block
DC
input, terminal block, 3.5 mm mic/line in, 3.5 mm line out
i-CS
connector (compatible with P-Iris and DC-iris)
manufacturer’s
supported connector, Security lock slot
Storage
Support
for microSD/microSDHC/microSDXC card
Support for SD card encryption (AES-XTS-Plain64 256bit)
Recording
to network-attached storage (NAS)
For
SD card and NAS recommendations, refer to the manufacturer's webpage
Operating conditions
-20
°C to 60 °C (-4 °F to 140 °F)
Humidity
10–85% RH (non-condensing)
Storage conditions
-40
°C to 65 °C (-40 °F to 149 °F)
Humidity
5–95% RH (non-condensing)
Dimensions
214
x 80 x 68 mm (8.4 x 3.2 x 2.7 in)
Weight
790
g (1.7 lb)
Optional lenses
Lens
CS 4-10 mm F0.9 P-Iris
Lens
i-CS 9-50 mm F1.5 8 MP
Lens
CS 12-50 mm F1.4 P-Iris 8 MP
Languages
English,
German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese,
Korean, Portuguese, Polish, Traditional Chinese, Dutch, Czech, Swedish,
Finnish, Turkish, Thai, Vietnamese
Warranty
5-year
warranty
