Image sensor
Uncooled microbolometer 384x288 pixels, pixel size 17 μm.
Spectral range: 8-14 μm
Lens
Athermalized
Horizontal
field of view: 55°, F1.18
Minimum
focus distance: 1.3 m (4.3 ft)
Sensitivity
NETD
40 mK @25C, F1.0
Object temperature
range
-40
°C to 350 °C (-40 °F to 662 °F)
Temperature accuracy
Below
120 °C (248 °F): ±5 °C (±9 °F) accuracy
Above
120 °C (248 °F): ±15% accuracy
Detection range
We
recommend the size of a monitored object to cover at least 10x10 pixels in
384x288.
General
Spot
temperature meter, up to 10 polygon temperature detection areas
System on Chip model
Manufacturer’s
own chipset (8th gen)
Memory
2048
MB RAM, 8192 MB Flash
Compute capabilities
Deep
learning processing unit (DLPU)
Video compression
H.264
(MPEG-4 Part 10/AVC) Baseline, Main and High Profiles
H.265
(MPEG-H Part 2/HEVC) Main Profile
Motion
JPEG
Resolution
Sensor
is 384x288. Image can be scaled up to 768x576.
Frame rate
Up
to 8.3 fps or 30 fps
Video streaming
Up
to 20 unique and configurable video streams
Controllable
frame rate and bandwidth
VBR/ABR/MBR
H.264/H.265
Video
streaming indicator
Image settings
Contrast,
brightness, sharpness, local contrast, exposure zones, compression, rotation:
0°, 90°, 180°, 270° including corridor format, mirroring, text and image
overlay, polygon privacy mask, electronic image stabilization, multiple color
palettes
Audio features
AGC
automatic gain control
Speaker
pairing
Spectrum
visualizer
Audio streaming
Configurable
duplex:
One-way
(simplex, half duplex)
Audio input
Input
through speaker pairing
10-band
graphic equalizer
Input
for external unbalanced microphone, optional 5 V microphone power
Digital
input, optional 12 V ring power
Unbalanced
line input
Audio output
Output
through speaker pairing
Audio encoding
24bit
LPCM, AAC-LC 8/16/32/44.1/48 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz, Opus
8/16/48 kHz
Configurable
bit rate
Network protocols
IPv4,
IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS, HTTP/2, TLS, QoS Layer 3 DiffServ, FTP,
SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP®, SNMP v1/v2c/v3 (MIB-II),
DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP,
DHCPv4/v6, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424,
UDP/TCP/TLS), Link-Local address (ZeroConf)
Application Programming
Interface
Open
API for software integration. application includes Native SDK and Computer
Vision SDK.
ONVIF®
Profile G, ONVIF® Profile M, ONVIF® Profile S, and ONVIF® Profile T,
specifications at onvif.org
Onscreen controls
Electronic
image stabilization
Heater
Event conditions
Application:
early fire detection
Audio:
audio detection, audio clip playing, audio clip currently playing
Call:
state, state change
Device
status: above operating temperature, above or below operating temperature,
below operating temperature, within operating temperature, IP address removed,
new IP address, network lost, system ready, ring power overcurrent protection,
live stream active
Digital
audio input status
Edge
storage: recording ongoing, storage disruption, storage health issues detected
I/O:
digital input, manual trigger, virtual input
MQTT:
subscribe
Scheduled
and recurring: schedule
Video:
average bitrate degradation, tampering, temperature detection
(above/below/increasing/decreasing)
Event actions
Audio
clips: play, stop
I/O:
toggle I/O once, toggle I/O while the rule is active
MQTT:
publish
Notification:
HTTP, HTTPS, TCP, and email
Overlay
text
Pre-
and post-alarm video or image buffering for recording or upload
Recordings:
SD card and network share
SNMP
traps: send, send while the rule is active
Upload
of images or video clips: FTP, SFTP, HTTP, HTTPS, network share, and email
Built-in installation
aids
Pixel
counter
Applications
Included
video
motion detection, motion guard, fence guard, loitering guard, early fire
detection, active tampering alarm, audio detection
Supported
perimeter
defender
Support
for enabling installation of third-party applications
Product markings
ATEC,
IECEx, cULus
Supply chain
TAA
compliant
EMC
CISPR
35, CISPR 32 Class A, EN 55035, EN 55032 Class A, EN 50121-4, EN 61000-3-2, EN
61000-3-3, EN 61000-6-1, EN 61000-6-2, IEC 62236-4
Australia/New
Zealand: RCM AS/NZS CISPR 32 Class A
Canada:
ICES-3(A)/NMB-3(A)
USA:
FCC Part 15 Subpart B Class A
Railway:
IEC 62236-4
Safety
CAN/CSA
C22.2 No. 62368-1 ed. 3, IEC/EN/UL 62368-1 ed. 3, IS 13252
Environment
IEC
60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC
60068-2-78, IEC/EN 60529 IP66/IP67, IEC/EN 62262 IK10, ISO 21207 Method B,
NEMA 250 Type 4X
Network
NIST
SP500-267
Cybersecurity
ETSI
EN 303 645, FIPS 140
Explosion
IEC/EN
60079-0, IEC/EN 60079-7, IEC/EN 60079-31, UL 60079-0, UL 60079-7, UL 60079-31,
CSA C22.2 No. 60079-0, CSA C22.2 No. 60079-7, CSA C22.2 No. 60079-31, CSA C22.2
No. 213-17, UL121201
Certifications
ATEX:
II
3 G Ex ec IIC T4 Gc
II
2 D Ex tb IIIC T135°C Db
Certificate:
UL 22 ATEX 2732X, UL 22 ATEX 2888X
IECEx:
Ex
ec IIC T4 Gc
EX
tb IIIC T135°C Db
Certificate:
ULD 22.0011X
cULus:
Class
I Div 2 Group A, B, C, D T4
Class
II Div 2 Group F, G T135°C T4
Class
III Div 2
Class
I Zone 2 AEx ec IIC T4 Gc
Zone
21 AEx IIIC T135°C Db
Certificate:
E525121
Edge security
Software:
Signed OS, brute force delay protection, digest authentication and OAuth 2.0
RFC6749 OpenID Authorization Code Flow for centralized ADFS account management,
password protection
Hardware:
cryptographic compute module cybersecurity platform
TPM
2.0 (CC EAL4+, FIPS 140-2 Level 2), secure element (CC EAL 6+), system-on-chip
security (TEE), Manufacturer's device ID, secure keystore, signed video, secure
boot, encrypted filesystem (AES-XTS-Plain64 256bit)
Network security
IEEE
802.1X (EAP-TLS, PEAP-MSCHAPv2), IEEE 802.1AE (MACsec PSK/EAP-TLS), IEEE
802.1AR, HTTPS/HSTS, TLS v1.2/v1.3, Network Time Security (NTS), X.509
Certificate PKI, host-based firewall
Casing
IP66/IP67-,
NEMA 4X-, and IK10-rated
Polycarbonate
blend and aluminum, germanium window
Color:
gray NCS S 5502-B
Power
Power
over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 3
Typical
4.3 W, max 12.95 W
10–28
V DC, typical 4.1 W, max 12.95 W
Connectors
Network:
Shielded RJ45 10BASE-T/100BASE-TX/1000BASE-T PoE
I/O:
Terminal block for 1 supervised alarm input and 1 output (12 V DC output, max.
load 50 mA)
Audio:
3.5 mm mic/line in
Power:
DC input, terminal block
Storage
Support
for microSD/microSDHC/microSDXC card
Recording
to network-attached storage (NAS)
For
SD card and NAS recommendations, refer to the manufacturer's webpage
Operating conditions
-30
°C to 60 °C (-22 °F to 140 °F)
Humidity
10–100% RH (condensing)
Storage conditions
-40
°C to 65 °C (-40 °F to 149 °F)
Humidity
5-95% RH (non-condensing)
Dimensions
For
the overall product dimensions, see the dimension drawing in this datasheet.
Effective
Projected Area (EPA): 0.022 m2 (0.24 ft2)
Weight
1.5
kg (3.3 lb)
Box content
Camera,
installation guide, TORX® L-keys, terminal block connectors, connector guard,
cable gaskets, owner authentication key
Languages
English,
German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese,
Korean, Portuguese, Polish, Traditional Chinese, Dutch, Czech, Swedish,
Finnish, Turkish, Thai, Vietnamese
Warranty
5-year
warranty
Export control
This
product is subject to export control regulations, and you should always comply
with all applicable national and international export or re-export control
regulations.
Substance control
PVC
free, BFR/CFR free in accordance with JEDEC/ECA Standard JS709
RoHS
in accordance with EU RoHS Directive 2011/65/EU and 2015/863 EN IEC 63000:2018
REACH
in accordance with (EC) No 1907/2006.
Materials
Screened
for conflict minerals in accordance with OECD guidelines
Environmental
responsibility
The
manufacturer is a signatory of the UN Global Compact, read more at
unglobalcompact.org
